FrSky RXSR-FC OMNIBUS F4 V6

The FrSky RXSR-FC (OMNIBUS F4 V6) uses the MPU6000 over SPI to produce stable flight performance. Integrated with the RXSR receiver mounted onboard in a protective box. It also features a barometer and AB7456 OSD chip for the Betaflight integrated OSD.

The RXSR-FC (OMNIBUS F4 V6) supports 3-6s Lipo direct input and has 5 hardware UARTs.

Features

• RXSR Receiver
• STM32 F4 Processor
• MPU6000 Gyro via SPI
• BMP280 Barometer
• Integrated Betaflight OSD
• 5 UART Ports
• Direct plugin 3-6S Lipo
• Built-in LC Filter
• 5V 1000mA BEC
• 8V 1000mA BEC
• More caps to reduce gyro power noise.

Specifications

• STM32 F405 MCU, Runs Betaflight firmware (supported from v3.2)
• FrSky RXSR receiver in protection box
• MPU6000 over SPI Bus
• 30.5×30.5 mm mounting holes
• Supports Lipo direct plug-in (3-6S)
• Supports 5V 1A BEC output (Buck)
• Supports 8V 1A BEC with LC filter output for the camera and VTX (Buck)
• STM32 controls OSD chip over SPI in DMA mode (Betaflight OSD)

Includes

• 1x Flight controller
• Manual
