F4 FCs
DarwinFPV AIO F411 1-3S 15A 4in1 ESC
Multirotors → FPV Racing drones → Flight controllers → F4 FCs → FC F4 + ESC 4in1 Stacks → DarwinFPV AIO F411 1-3S 15A 4in1 ESC
Specifications:
Brand: DarwinFPV
Item Name: F411 AIO Flight Controller
ESC:
Input Voltage: 3~13.5V DCIN(1~3SLiPo)
Constant Current: 15A
Peak Current: 17A
BEC Ouput: No
MCU: 48MHz EFM8BB21F16G
Protocol:DSHOT/Oneshot/MultiShot
BLHeli_S Firmware target： S-H-50
Telemetery:No
Current Sensor:No
Flight Controller:
MCU: 100MHz STM32F411CEU6
IMU: MPU6000(SPI)
Baro: No
Blackbox: No
OSD:AT7456E
2xUarts(1,2)
Built in inverter for SBUS input (UART1-RX)
1xSoftserial supported(S5)
3~13.5V DCIN(1~3SLiPo)
BEC:5V 2A cont.(Max 2.5A)
LDO3.3V: Max 200mA
Battery Voltage Sensor: 1:10(Scale110)
BetaFlight target: MATEKF411
Package included:
1X F411 AIO Flight Controller
