Pandarc VT5804 BAT 5.8G 40CH 25-2500mW 2.5W VTX

FPV → FPV 5.8GHz → Video TX 5.8GHz → PandaRC VTXs 5.8GHz → Pandarc VT5804 BAT 5.8G 40CH 25-2500mW 2.5W VTX

VT5804-BAT

Output power: 0-25-400-800-1500-2500mW

Input voltage: 6-36V

Parameter adjustment method: key/OSD

Working current: less than or equal to 450mA@12V, 800mW

Less than or equal to 850mA@12V, 2500mW

Output frequency: 40CH (A-B-E-F-R)

Antenna interface: MMCX

Installation hole: 30.5*30.5mm-20*20mm

Video format: NTSC/PAL automatic detection

Weight: 11g (without antenna and power cord)

Size: 38*36.5*7.2mm

1. With its own power self-check function, you can quickly check whether the image transmission is working normally

2. Frequency lock function, no interference with companions when power on

3. It has 30.5*30.5 and 20*20 mounting holes at the same time to improve the compatibility of rack

4.0-2.5W power adjustable, allowing you to switch seamlessly in different environments

Features:

1. With its own power self-check function, you can quickly check whether the image transmission is working normally

2. Frequency lock function, no interference with companions when power on

3. It has 30.5*30.5 and 20*20 mounting holes at the same time to improve the compatibility of rack

4.0-2.5W power adjustable, allowing you to switch seamlessly in different environments

Specification:

Brand: Pandarc

Model: VT5804-BAT

Output power: 0-25-400-800-1500-2500mW

Input voltage: 6-36V

Parameter adjustment method: key/OSD

Working current: Less than or equal to 450mA@12V, 800mW

Less than or equal to 850mA@12V, 2500mW

Output frequency: 40CH (A-B-E-F-R)

Antenna interface: MMCX

Installation hole: 30.5*30.5mm-20*20mm

Video format: NTSC/PAL automatic detection

Weight: 11g (without antenna and power cord)

Size: 38*36.5*7.2mm

Package Included:

1x VT5804-BAT VTX
