Flywoo GOKU F745 nano

This is a smallest but most spowerful F745 flight controller packed with features including a barometer, blackbox, 7 complete hardware serial ports, I2C functionality and WS2812 LEDs on each corner.
It is specifically designed to be pin mounted to the Goku BS13A / 20A / 35A 4in1 16x16 ESCs but can also be soldered via pads. The programmable WS2812 LED on each corner provide low profile lighting for this tiny FC.


Specifications

  • SIZE: 22*23mm Weight: 2.3g
  • Hole: 16*16-3mm
  • MCU: STM32F745
  • UARTS: 1/2/3/4/5/6/7
  • I2C: SCL/SDA
  • GYRO: MPU6000
  • BARO: BMP280 BEC: 5V 2A
  • LED:4*WS2812 FLASH: 8M
  • Input Voltage: 2-6S
  • Firmware: FLYWOOF745NANO
