SkyStars KO60 4in1 BL32-60A ESC

The Skystars KO series BLHeli_32 4-in-1 ESCs have a 6-layer design and over-current capabilities. And with BLHeli_32 firmware, you won't be bottlenecked by your ESC.

Features

• Supports telemetry functions (including Voltage, RPMS, & Current)
• Toshiba standard 40V 5x6 Mosfet & electronics
• Lead-free SMT Processing technology
• ESC Onboard Current Sensor
• Over-Current Capabilities
• Supports 6S Batteries
• 6-layer Layout Design
• BLHeli_32 Firmware

Specifications

KO45 - 45A

• Drive signal: Dshot300-1200 / Proshot1000 / Oneshot / Multishot / PWM
• MCU: STM32F051 Operation frequency: 48MHz
• Peak current [5 seconds]: 55A
• Mount: 30.5mm x 30.5mm
• Continuous current: 45A
• Firmware: BLHeli_32
• ESC weight: 12g
• Supports 3-6S
• BEC: No

KO60 - 60A

• Drive signal: Dshot300-1200 / Proshot1000 / Oneshot / Multishot / PWM
• MCU: STM32F051 Operation frequency: 48MHz
• Peak current [5 seconds]: 65A
• Mount: 30.5mm x 30.5mm
• Continuous current: 60A
• Firmware: BLHeli_32
• ESC weight: 12g
• Supports 3-6S
• BEC: No

Includes

• 1x Skystars BLHeli_32 4-in-1 3-6S 30x30 ESC (45A or 60A optional)
• 1x 35v 560uf Capacitor
• 4x Rubber Grommet
• 1x Wire Harness
• 1x XT60 Cable
