Diatone MAMBA AIO F722 35A MK1 External USB
Multirotors → FPV Racing drones → Flight controllers → F7 FCs → FC F7 AIO built-in ESC 4in1 → Diatone MAMBA AIO F722 35A MK1 External USB
| MCU: | F722 |
| Gyro: | MPU6000 |
| Barometer: | + |
| OSD: | + |
| Power : | 2-6S |
| 5V BEC: | 2.5A |
| Current Sensor: | + |
| ESC type: | built in |
| ESC: | 4x35A |
| BLHeli: | BLHeli_S |
| UART Rx: | 5 |
| UART Tx: | 5 |
| Buzzer pad: | + |
| LED pad: | + |
| Blackbox: | - |
| USB: | External Micro USB / Type C |
| DJI compatible: | + |
| Size: | 34x34x5.7mm |
| Mount Holes: | 25.5x25.5mm |
| Weight: | 8g |
FC Specifications
- MCU: 216MHz STM32F722RET6
- GYRO: MPU6000
- Barometer: Yes
- OSD: Yes
- Blackbox: NO
- Uarts: 5 Set
- ESC Soft: Dshot300/600
- Power Led: Yes
- LED Controller: BF LED
- F.Port: Yes
- RSSI: No
- Buzz: Yes
- Input: 2~6S Lipo (8.4~25.2V)
- TVS Protection: Yes
- BEC: 5V 2.5A
- MOUNTING: 25.5mm ,M2
ESC Specifications
- MAMAB AIO 35A F722MK1 (EXTERNAL USB)
- INPUT VOLTAGE: 2~6S Lipo (8.4V~25V)
- CONTINUE CURRENT: 35A×4
- BURST CURRENT: 45A (10S)
- Target：BLHeli_S GH30
- SOFT: Dshot300/600
Supply :
- High-Frequency 470uF/35V ×1
- 7pin sh1.0 ×2
- 16AWG 60mm ×2
- AMASS Original XT60
Share
Prices for Diatone MAMBA AIO F722 35A MK1 External USB in stores
Deals found: 17 (NewBeeDrone1, Banggood1)
| Store | Stock level | Lot price | Shipping cost | Coupon / promocode | Pcs./lot | 1pc price |
| NewBeeDrone | Stock level: 18 | $61 | 1 | $61 | ||
| Banggood | Out of stock | $100 | 1 | $100 |
