HGLRC Zeus F722 mini 6S
Multirotors → FPV Racing drones → Flight controllers → F7 FCs → HGLRC Zeus F722 mini 6SRecommended stores↓ Another stores
HGLRC Zeus F722 mini 2-6S F722 Flight Controller
Updated on June 18th, now supports M2/M3, added DJI air unit port
Usage: for 100mm-450mm Frame Kit
FC Firmware: BF HGLRCF722(HGLR)
Installing Hole: 20X20mm.M2/M3
Item Name:Zeus F722 mini Flight Controller
MPU:MPU6000
UARTS:5
CPU:STM32F722 RET6
Input Voltage:2-6S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output:9V/2A
5V/3A
BlackBox:8M
Barometer:BMP280(I2C)
Size:28.2x28.1mm
Installing Hole:20X20mm.M2/M3
Weight:4.6g
Product Features:
1.Integrated barometer and 8M black box.
2.Maximum BEC 9V/2A and BEC 5V/3A output
3.Easy direct soldering for XM+, Crossfire NANO receiver
4.Quickly connect DJI Air Unit.
Includes
1x Zeus F722 mini Flight Controller
5x M3 Shock absorption（red）
5x M3 to M2 Stack Mount Adapter
1x SH1.0 8PIN 60mm Cable
1x DJI AIR UNIT PORT CABLE 90mm
See manual here：F722 MINI Flight controller
Share
Prices for HGLRC Zeus F722 mini 6S in stores
Deals found: 57 (ReadyMadeRC1, Banggood1, AliExpress1)
| Store | Stock level | Lot price | Shipping cost | Coupon / promocode | Pcs./lot | 1pc price |
| ReadyMadeRC | Out of stock | $25 | 1 | $25 | ||
| Banggood | Out of stock | $52 | 1 | $52 | ||
| AliExpress | High stock level | $60 | 1 | $60 |
