Flycolor X-Cross HV V2 80A 12S ESC

Main Feature

• ARM 32-bit Cortex MCU, frequency up to 48MHz
• International famous brand MOSFET with high performance and low ESR, not afraid of large current
• BL Heli_32 firmware, u0 to 12S Lipo, suitable for X Class frame drone
• Supports regular 1-2ms pulse width input, as well as Oneshot125, Oneshot42 and Multishot.
• The input signal is automatically detected by the ESC upon power up
• Small size, light weight, suitable for the drone with narrow arms
• Damped light does regenerative braking, causing very fast motor retardation, and inherently also does active freewheeling
• The silicone twisted-pair of the throttle signal cable effectively reduces the crosstalk caused by signal transmission, and makes flight more stable
• Aluminum heatsink effectively slow down the temperature rise

Specification

• Con. Current: 80A
• Burst Current: 100A
• Lipo: 5-12S
• Weight: 25.5g
• Size: 55×28×10mm
