GEPRC GR1204 5000KV

Overview:

GR1204 brushless motor, designed for Whoop Drone and Toothpick Drone, High efficiency and smooth.

Specification:

• Model:GR1204
• KV: 5000KV
• No. of Cells (Lipo): 5000KV @ 3-4S
• Configu-ration: 9N12P
• Stator Diamter: 12mm
• Stator Length: 4mm
• Shaft Diameter: Φ1.5mm
• Motor Dimension(Dia.*Len): Φ15.28*10.9mm
• Rotor: N52H arc magnets
• Base casing : 7075-T6
• Weight: 3.8g
• Application: compatible with 105mm-110mm RC Drone(Whoop Drone and Toothpick Drone)

Features:

• High efficiency and smooth
• Better for Toothpick or Whoop Drone building
• Dual bearing design and more balance
• Compatible with 40mm-75mm propellers and 1-4S Lipo battery

Package included:

• 1x GEPRC GR1204 Motors
• 4x M3x4 Button head screws
• 4x M3x5 Button head screws
• 4x M3x7 Button head screws
